Automatic Wide Paper Film Jumbo Roll to Sheet Cutter with Un

Product Details:

Place of Origin: China
Brand Name: JUANXIN
Certification: CE
Model Number: CXY-600G

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: wooden case or carton box
Delivery Time: 3-5 days
Payment Terms: FOB/EXW/CIF
Supply Ability: 1000 set /week
Detailed Product Description

Automatic Wide Paper Film Jumbo Roll to Sheet Cutter with Unwinder Paper Sheet Cutting Machine

YouTube video: https://youtu.be/J0-GGWyett4
                            https://youtube.com/shorts/GNpBpJL3MOY?feature=share
                            https://youtube.com/shorts/GNpBpJL3MOY?feature=share


Applicable industries: electric appliance, packaging, leather, bags and suitcases, toy, outdoor supplies, garment factory, etc.



Usage: used to cut PVC film, aluminum/copper/nickel foil, PET film, insulation paper, A4/A3 paper, non-woven fabric, reflective transfer film, heat shrink sleeve, artificial leather, PE film, foam, air bubble film, plastic sheet, etc



Specification:

Voltage

220V/110V 50HZ/60HZ

Power

1.2KW

Cutting Width

1-600MM (other width is optional)

Cutting Length

0.1-99999.9MM

Tolerance

0.002XCutting Length

Cutting Speed

100pcs/min (L=50mm)

Feeding Speed

700MM/second

Display

English & Chinese LCD Screen

Weight

270KG

Size

1100*950*1250MM

Package

Wooden case (1300*970*1250MM)

Warranty

One year warranty for whole machineand three years warranty for motor motherboard system.
Lifelong service.

Certification

CE



Features:

1. Easy to operate---micro-computer control panel, English instructions and display

2. Durable blade---premium cutting blade made from SKD-11 high speed steel

3. Accurate feeding---upper and lower polyurethane rollers working same time to guarantee accurate feeding and cutting; roller is pressure proof & hard wearing & heat resisting

4. Accurate cutting---material straightening device to avoid deviation

5. Easy feeding---vertical aluminum frame with for feeding various material rolls

6. Durable---quiet cooling fan to cool the machine and lengthen the service life with high performance

7. Stable performance---high precision (0.1mm) and strong feeding motor controlled by motherboard system

8. Flexible---customization accepted for special cutting
