JX-360 Multi-Core Cable Cutting And Stripping Machine

Product Details:

Place of Origin: China
Brand Name: JUANXIN
Certification: CE
Model Number: JX-360

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: negotiation
Packaging Details: wooden case or carton box
Delivery Time: 3-5 days
Payment Terms: FOB/EXW/CIF
Supply Ability: 1000 set /week
Detailed Product Description

JX-360 Automatic Multi-Conductor Cables Cut And Strip Machine For Max 8mm OD Cables

Intro:



RS-360 is full automatic type wire cutting and stripping machine. It can work for both electric single core wire within 10 sqmm and multi-conductor cables with max 8MM OD. Cut length is 0.1-9999MM adjustable. Standard machine can make max 50MM strip length. If you need longer strip length, we can modify it to strip 200MM or longer.



  • Note: For round multi-conductor cable, it can cut and strip outer insulation only. You need to use RS-3F for stripping inner insulation.
  • For flat double-core cable, it can cut and strip both outer& inner insulation.

Suitable:



1. Multi-functional wire cutter and stripper, High accuracy, Fast speed

2.Suitable for round muti-core cable within 8MM OD. Or electric wire within 10 sqmm.

3. Cut and strip function

4.With big 60/100 stepping motor and 12MM conductor, for different size of cables



Specification:



Model JX-360
Power Supply 220V/110V 50HZ/60HZ
Name Automatic wire cutting and stripping machine
Available wire Muti-core cables, power cable/cord and electrical wires,etc Suitable for PVC/PTFE/silica gel line /Glass fiber etc.
Max cable diameter 8.0MM
Strip length Max 50MM. For longer strip length, RS-360T is OK
Cable size Within AWG8 (10sqmm)
Weight 32KG



Feature:



1. Fast speed cutting and stripping machine for wiring harness processing.

2. Multi-functional machine. For electric single core wire, multi-conductor cable.

3. LCD display shows parameters. Press buttons to set length, quantity,etc.

4. Nice appearance, simple operation,convenient maintenance, stable performance, speed, precision higher character.

5. Cut length and strip length can be adjustable easily.

6. Different working mode for different types of wires.
